High-Intensity Microprismatic Reflective Sheeting – R100 Series (Specification Summary)

The R100 Series is a high-intensity, microprismatic retroreflective sheeting designed for permanent and temporary traffic control signage. Its omni-directional microprismatic construction delivers uniform brightness and visibility from multiple viewing angles, providing consistent performance in demanding roadway and safety environments.

Key Performance Features

• Retroreflective Type: ASTM D4956 Type III / IV (High-Intensity Performance)

• Optical Design: Omni-directional microprismatic construction for balanced, multi-angle visibility

• Durability: Up to 10 years for vertical outdoor exposure

• Service Temperature Range: -10°F to +150°F (-23°C to +65°C)

• Minimum Application Temperature: 50°F (10°C)

• Film Thickness: Approx. 14–19 mils

• Adhesive System: Permanent pressure-sensitive adhesive

• Shelf Life: 1 year when stored under recommended conditions

• Substrate Compatibility: Properly prepared aluminum surfaces

Available Colors

• White

• Yellow

• Green

• Red

• Blue

Industry Standards & Global Compliance

The R100 Series meets or exceeds multiple international reflective performance standards, including:

• ASTM D4956 Type III / IV

• EN 12899-1 (RA2 / R2)

• AS/NZS 1906.1 Class 300

• JIS Z9117

• GB/T 18833 Type IV

• IRAM 3952 Class II
  and additional regional roadway-signage standards worldwide.

Warranty & Performance Assurance

The R100 Series carries a 10-year retroreflectivity performance warranty for vertical installations, retaining a minimum of 80% of initial brightness values when properly fabricated, installed, and maintained. The warranty covers natural weathering deterioration under normal roadway exposure conditions and is subject to installation and handling requirements.
